Hot Rolled Coils, Sheets & Plates - Features
JSW Steel manufactures Hot Rolled (HR) coils at its state-of-the-art Hot Strip Mills (HSM), at Vijayanagar (Karnataka) and Dolvi (Maharashtra).
Vijayanagar HSM-I and HSM-2 with commissioned capacities of 3 MTPA and 5 MPTA respectively are equipped with sizing presses and an automatic line inspection facility. HSM at Dolvi Works has capacity of 3.6 MPTA which uses a combination of the advanced Conarc Process and Thin Slab Casting technology, facilitating the production of HR coils. Due to their thinner gauges and finer surface quality, these are often superior to commercial grade cold rolled (CR) coils and may substitute for CR products in certain applications. The convenient coastal location of Dolvi unit facilitates easy access to plant and makes the import and export of raw materials and finished good extremely cost effective.
Download Brochure
Salient Features
- Range of HR products: Thickness upto 25.4mm, Width upto 2050mm and Coil Weight upto 36mt.
- Ultra-Low Carbon for IF & IFHS grade and Dual Phase steel requiring divide quench cooling for critical automobile applications
- One of the very few manufacturers in the world to manufacture X70 grade up to 20mm thickness for Line Pipe applications
- Higher reduction in finishing stands with transfer bar thickness up to 55mm
- Level2 coiling temperature control to achieve desired cooling pattern and rates for control of micro-structure
Hot Rolled - Coils, Sheets & Plates
Thickness |
1.2 - 25.4mm |
Width |
900-2100 mm |
Grades |
- Re-rolling/ Drawing Grades,
- Tube and Pipe/ Forming Grades,
- Structural/ Medium Tensile Tube/ Forming Grades,
- LPG/ Low Pressure Vessel Grades,
- HSLA Grades,
- Medium Carbon Grades,
- Weather Resistance Grades,
- Line Pipe Grades,
- Chequered Plates
View All Grades »
|
Hot Rolled - Cut-to-Length Sheets
Thickness |
1.2 - 25.4mm |
Width |
900-2050 mm |
Length |
1000 - 13000 mm |
Hot Rolled - Pickled & Oiled (HRPO)
Thickness |
1.6 - 6.0mm |
Width |
1650mm |
Hot Rolled - Skin Pass Pickled & Oiled (HRSPO)
Thickness |
1.6 - 2.6mm |
Width |
1650mm |
